LITTEL MULTI-SWITCH – SERIES 36000, 37000, & 38000
FAX: 773 792-2129
?
SWITCHES
305
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
LITTEL ? MULTI-SWITCHES
SERIES 36000, 37000, 38000 (continued)
SERIES 37000
PART NUMBERS / 2-C PER STATION 1
SERIES 38000
PART NUMBERS / 2-C PER STATION 1
Interlock
Push-Lock/
Number of
Interlock
Push-Lock/
Number of
with Lock-Out
? 37021K1206
? 37041K1206
? 37061K1206
? 37081K1206
? 37101K1206
? 37121K1206
Non-Lock
? 370221206
? 370421206
? 370621206
? 370821206
? 371021206
? 371221206
Push-Release
? 370271206
? 370471206
? 370671206
? 370871206
? 371071206
? 371271206
Stations 2
2
4
6
8
10
12
with Lock-Out
? 38021K1206
? 38041K1206
? 38061K1206
? 38081K1206
? 38101K1206
? 38121K1206
Non-Lock
? 380221206
? 380421206
? 380621206
? 380821206
? 381021206
? 381221206
Push-Release
? 380271206
? 380471206
? 380671206
? 380871206
? 381071206
? 381271206
Stations 2
2
4
6
8
10
12
PART NUMBERS / 4-C PER STATION 1
PART NUMBERS / 4-C PER STATION 1
? 37021K1212
? 37041K1212
? 37061K1212
? 37081K1212
? 37101K1212
? 37121K1212
? 370221212
? 370421212
? 370621212
? 370821212
? 371021212
? 371221212
? 370271212
? 370471212
? 370671212
? 370871212
? 371071212
? 371271212
2
4
6
8
10
12
? 38021K1212
? 38041K1212
? 38061K1212
? 38081K1212
? 38101K1212
? 38121K1212
? 380221212
? 380421212
? 380621212
? 380821212
? 381021212
? 381221212
? 380271212
? 380471212
? 380671212
? 380871212
? 381071212
? 381271212
2
4
6
8
10
12
1. Switches with all-lock function are available on special order.
Contact Switchcraft.
2. Odd number of stations (3, 5, 7, 9, 11) are available. Switches with
13 through 18 stations also available. Contact Switchcraft.
? Special order only; Contact Switchcraft for price and delivery information.
TYPICAL PANEL OPENING
1. Switches with all-lock function are available on special order.
Contact Switchcraft.
2. Odd number of stations (3, 5, 7, 9, 11) are available. Switches with
13 through 18 stations also available. Contact Switchcraft.
? Special order only; Contact Switchcraft for price and delivery information.
MATERIAL SPECIFICATIONS
Frame: Steel, dry film lubricant.
Plungers, Stack Switch Mounting Brackets and Screws:
Steel, plated.
Stack Switches: Stack switch springs are made of copper
alloy. Solder lugs are hot tin-dipped.
Insulation: Stack switches: rigid plastic spacers with
plastic tubing through stack.
Lifters: Thermoplastic.
SERIES 37000, 38000
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
